- complete package with U 5 KS submersible pump, 10 m cable and plug
- max. delivery head 8 m
- max. flow rate 11.5 m³/h
- robust plastic carrying basket 300 × 400 mm
- 12.5 m fire hose with C-coupling on both sides
- pump holder and clip for fixing the level switch
- personal protection adapter plug
- 30 mA
- pump set, ideal for pumping drainage and ground water
- can be used in drainage shafts with sand traps from 280 mm diameter
- max. delivery head 9 mWS
- max. flow rate 15.5 m³/h
- integrated level switch for narrow shafts
- cable end with connector housing and integrated H-0-A switch
- pump can be activated manually with float in OFF-position
- volute with 20 mm free passage and removable strainer
- pre-assembled with R32 non-return valve and stainless steel safety catch
- GRP housing, pressure connection hose nozzle d40 with vertical discharge
- protection class IP68, longitudinally watertight moulded cable entry
- dry-run safe, mechanical seal with oil chamber on the media side
- speed 2900 1/min, motor protection winding thermostat
- pre-assembled, ready-to-connect installation set for sumps from 500 × 500 mm
- for the alternating operation of two submersible pumps
- suitable for U3 KS (special), U5 KS and U6 K ES (pumps not included)
- 2× GR 32 guide-rail system (quick self-coupling of pumps)
- 2× non-return valve R32, pressure pipe DN 32
- 2× elastic connectors for pressure pipe OD 40 mm, straight and elbow
- plug-ready EasyLogo pump control unit with alarm circuit included in scope of delivery
- pre-assembled, ready-to-connect installation set for shafts from 400 × 300 mm
- suitable for U3 KS (special), U5 KS and U6 K ES (pump not included)
- GR 32 guide-rail system (quick self-coupling of pumps)
- non-return valve R32, pressure pipe DN 32
- straight elastic connection for pressure pipe OD 40 mm
- enables manual pumping down to a water level of less than 1 cm
- mounting kit for installing a pump with quick self-coupling in a sump pump
- suitable for U3 KS (special), U5 KS and U6 K ES (pump not included)
- without self-locking nut on impeller
- material: nodular cast iron (GGG40)
- working pressure: 10 bar
- maximum temperature: 100 °C
- epoxy coating
- GRP housing with G 1 ¼" female connection
- drain plug to drain the pressure pipe
- GRP housing with G 2" female connection
- Drain plug to drain the pressure pipe
AQUATO® TOPSELLER
- AQUATO® menu structure
- for AQUATO SBR, fixed bed and moving bed systems as well as trickling filter systems and plant beds
- 4 cables with square plugs for the valves Possibility of pressure and current monitoring
- integrated power failure notification
- use for 3 or 4 valve manifolds
- optional connection of a clear water pump
- IoT capability/portal required
- AQUATO® menu structure
- universal control for SBR, SSB®, fixed bed, moving bed, trickling filter systems and plant beds
- 2 float switch inputs
- 6 individually assignable outputs
- easy connection of existing valves and aggregates
- internal thermostat for control of a cabinet ventilation or heating system
- power failure message as well as current & pressure monitoring
- drain class C, N, D, D+P, D+H, D+P+H
- connection of an additional high water detector
- also suitable for plants of other manufacturers
- 2nd compressor, additional compressor (only for aeration), charging pump, clear water pump, excess sludge pump, buffer pump/siphon,
dosing pump for effluent class D+P, UV lamp for effluent class D+H, additional timed relays for all free outputs
- submersible up to 12 m deep
- suitable for pumping clean, chemically neutral water
- for use in cisterns and rainwater tanks
- integrated pressure switch for automatically switching the pump on and off
- integrated floating switch as dry-run protection
- housing is supplied without lock, key and without base plate for the compressor
- including fastening set
- connection pipe sideways G 1" male
- without connection cable
